Pensile air purifier for welding fumes

WFU18 pensile air purifier for welding fumes is designed to aspire and filter metal welding fumes and dust. Thanks to its compact size, WFU18 can be wall-mounted close to the stations producing pollutions. Its suction arm grants a work range of 3mt.

ADVANTAGES

  • Quick: fumes suction straight from the source thanks to a high flow rate.
  • Filtration: with absolute filter H13 ≥99.95%.
How the purifier works

Pollutants are aspired by the suction arm. Then, pollutants are filtered to 99,95% of efficiency while crossing the purifier.
Once air is clean, it is returned back into the environment via grids located on both sides of the machine.

aspiratore fumi di saldatura polveri 99,5% filtro HEPA carboni attivi braccio aspirante

Environment safety and certification

As requested by norms, level of clogging is constantly monitored by a system with a led signal, which advise when it is necessary to clean or substitute filters.

Accessories

  • Connection for external ejection of filtered air.

Technical data

Rated capacity 1.500 mc/h
Engine power 1,5kW 220/1/50
Total weight 150 kg ca
Filtration:
Stage 1 – sparkproof metallic filter G3
Stage 2 – acrylic filter G4 (following EN 779:2012)
Stage 3 – absolute filter H13 ≥99.95% (@ MPPS following EN 1822:2009)

Standard equipment

  • Brackets fot wall-mounting.
  • Electrical panel in accordance with CE rules, with on/off switch for ventilation and warning led for filter clogging.

Contact us for a quotation!

sectors of application

Metalwork
